J250K: 200 kW John Deere Diesel Generator

For large commercial facilities and critical infrastructure requiring substantial 50 Hz backup power, the J250K combines proven John Deere engineering with SDMO's generator design expertise. Powered by the turbocharged John Deere 6068HFS55-228 engine and paired with a brushless AT01180T alternator, this generator set is built for demanding standby and prime power applications across a broad range of international voltage configurations.

• Engine: John Deere 6068HFS55-228, 6.72L, 6-cylinder inline, turbocharged with air/water intercooling, 1500 RPM, electronic governor
• Output: 200 kW / 250 kVA standby (ESP); 182 kW / 227 kVA prime (PRP), three-phase, 0.8 power factor
• Voltage options: 200/115V, 220 TRI, 230 TRI, 240 TRI, 380/220V, 400/230V, and 415/240V, 50 Hz configurations
• Alternator: AT01180T, brushless, Class H insulation, IP21 protection, 4-pole, single bearing, direct coupling, +/-1% voltage regulation, THD below 2.8% on load
• Fuel consumption: 51.4 L/hr at 100% standby load; 35.9 L/hr at 75% load; 24.4 L/hr at 50% load
• Controller: APM303 standard with LCD display, Modbus RTU on RS485, manual and automatic modes, 12 stored events log
• Starting system: 12V DC starter, 12V charging alternator, DC starting battery with electrolyte included
• Compact version dimensions: 2398mm x 1114mm x 1535mm, dry weight 1800 kg, integral 340-liter fuel tank
• Soundproofed version (M226): 3508mm x 1200mm x 1830mm, dry weight 2400 kg, integral 340-liter fuel tank
• Standards: ISO 8528-1, delivered with oil and coolant rated to -30°C, frequency regulation +/-0.5%
• EPA Compliant: Export Only
• Version: Enclosed (Fully Weather Proof Silent Enclosure)

With a maximum standby output of 228 kW and a high BMEP of 24.69 bar, the J250K sustains reliable performance under variable loads, making it ideal for hospitals, data centers, hotels, and industrial plants where power continuity is non-negotiable.

J250K Engine and Fuel Performance

The John Deere 6068HFS55-228 runs at 1500 RPM with a 17:1 compression ratio and electronic governor delivering tight +/-0.5% frequency regulation. Exhaust gas flow reaches 617 L/s at 665°C, with heat distributed across 162 kW to exhaust, 88 kW to coolant, and 22 kW radiated to ambient for straightforward thermal management planning.

J250K Alternator and Control Panel Options

The AT01180T delivers a continuous nominal rating of 225 kVA at 40°C and 250 kVA standby at 27°C, with 93% full-load efficiency and THD below 2.8% on load. The standard APM303 controller covers manual and automatic operation with full electrical metering, Modbus RTU on RS485, and a 12-event fault log. The optional TELYS upgrades to a scroll-wheel display with USB and PC connectivity for more comprehensive monitoring.

Containment DW and DW 48H Enclosure Options for the J250K

The M226 DW double-wall enclosure measures 3560mm x 1200mm x 2182mm with an 868-liter integrated fuel tank for extended runtime. The M226 DW48 version adds a taller 2364mm profile and increases tank capacity to 1630 liters, delivering approximately 48 hours of continuous full-load operation without refueling.
