OVERVIEW
SDMO APM303 Digital Control Panel, P/N 31613629300
Introduction:
The APM 303 is a instrumentation and control system for generating
sets.
It can be found in the SDMO range for generating sets under 300 kVA.
* 12V and 24V operation
* No ECU communication
* Options available
* Modbus function
* Configurable via PC and screen
* AUTO & MAN modes
The advantages of the APM303:
→ Easy to use
→ Based on the Nexys
→ Supervision
→ Starter and solenoid valve cut off by Emergency Stop
→ Simple Man Machine Interface
→ Post-heating for cold countries
→ Same central console as the Nexys
→ Stack of 12 events
→ Retrofit adaptable for Nexys/APM303
→ Front of the APM303 controller in IP54
Nexys/APM 303 comparison:
| APM 303 | NEXYS | |
| Power supply voltage | 12/24 | 12 |
| Inputs/outputs | 7/5(6/3 configurable) | 8/7 (all fixed) |
| Electrical measurements | As standard: 3 * U and 3 * l | Optional: 3 * U and 3 * l |
| Analog measurements | As standard: oil pressure, coolant | Optional: oil pressure, coolant |
| Modbus communication | As standard | Not included |
| CAN bus management | External display | External display |
| Configuration update | Via PC tool and screen | Via screen |
| Dimensions | 108 x 108 (93 x 93 for the cutout) | 310*150 |
| Electrical protection | Min and Max Voltage and | Not included |
| Event stack | 12 | Not included |
Front panel:
Rear panel: connectors
Screens:
