Introducing the SDMO D300 Generator

The SDMO D300 is a powerful generator designed to meet your energy needs. It features a DOOSAN engine and an AT01800T alternator for consistent power.

Key Specifications:

• Engine: DOOSAN P126TI
• Alternator: Reliable AT01800T
• Standby Power Rating: 300 kVA / 240 kWe
• Prime Power Rating (PRP): 273 kVA / 218 kWe
• Standard Voltage & Frequency: 400/230 V at 50 Hz
• Performance Class: G3
• EPA Compliance: Export Only
• Version: Enclosed (Fully Weather Proof Silent Enclosure)

The compact version has a dry weight of 2410 kg and a tank capacity of 390 liters. It includes an electronic governor and a chassis with antivibration suspension.

Engine Characteristics of the SDMO D300

The DOOSAN P126TI engine utilizes a 6-cylinder arrangement and a turbo air inlet. It operates at 1500 RPM with a displacement of 11.05 C.I.

Fuel consumption is 58.10 L/h at 100% load and 43.60 L/h at 75% load. It has a 25-liter oil capacity and a maximum water temperature of 103°C.

Optional Control Panels

While the APM303 is standard, you can upgrade your setup. The TELYS panel is user-friendly, offering an ergonomic design with a large display screen and navigation wheel. It tracks parameters like working hours, oil pressure, and coolant temperature.

Alternatively, the APM802 command system features a touch screen for power plant management.

SDMO D300 Soundproofed Enclosures

For quieter operation, the soundproofed M227 enclosure is available. This setup measures 4004 mm in length, 1380 mm in width, and 2145 mm in height. It reduces the acoustic pressure level to 73 dB(A) at 7 meters. You can also opt for the M227 DW48 enclosure with a 2130-liter tank capacity.
