D275: 220 kW Doosan Generator

The D275 is a 220 kW, 275 kVA diesel generator set built around a Doosan engine, engineered for facilities that need dependable standby or prime power without unnecessary complexity. With a mechanically welded chassis, main line circuit breaker, and a choice of three control panel options, this generator is designed for straightforward, reliable operation.

• DOOSAN P126TI engine, turbocharged, 1500 RPM, electronic governor
• AT01512T alternator, three-phase, IP23 protection, Class H insulation
• Standby power rating of 220 kW / 275 kVA at 400/230V, 50Hz
• Prime power rating of 200 kW / 250 kVA
• Performance class G3 for transient response
• Mechanically welded chassis with antivibration suspension
• Main line circuit breaker included for protection
• Radiator rated for wiring temperatures up to 48/50°C with mechanical fan
• Charger DC starting battery with electrolyte, 24V charge alternator and starter
• Delivered with oil and coolant rated to -30°C
• Version: Enclosed (Fully Weather Proof Silent Enclosure)
• EPA Compliant: Export Only

This generator suits commercial buildings, light industrial sites, and facilities across multiple voltage configurations, since it's available in 220 TRI, 415/240, 400/230, 380/220, 200/115, 240 TRI, and 230 TRI setups. With a compact footprint and multiple control panel choices, the D275 adapts easily to a wide range of installation needs.

Doosan Engine Performance and Cooling

The Doosan P126TI engine runs at 1500 RPM with a turbocharged, air/air-cooled 6-cylinder inline design and a displacement of 11.05 cubic inches, delivering a maximum standby output of 272 kW at rated speed.

Fuel consumption comes in at 58.10 L/hr at 100 percent load, 43.60 L/hr at 75 percent load, and 30 L/hr at 50 percent load. The cooling system uses glycol-ethylene coolant with a 50.50-liter radiator and engine capacity, supported by a 7 kW fan rated for a maximum water temperature of 103°C.

Alternator Performance and Electrical Output

The AT01512T alternator delivers a continuous nominal rating of 250 kVA at 40°C and a standby rating of 275 kVA at 27°C, with an efficiency of 92.40 percent at full load. It operates on a single bearing with direct coupling and IP23 protection, using brushless technology without collars.

Total harmonic distortion stays below 2.5 percent both on load and off load, and the alternator supports seven different voltage configurations to match a wide range of electrical systems, from 220 TRI up to 230 TRI three-phase setups.

Flexible Control Panel Options

Three control panel choices let operators match monitoring capability to their needs. The APM303 comes standard, offering an LCD screen with phase-to-neutral and phase-to-phase voltage readings, current and power factor measurements, a kWh energy meter, and Modbus RTU communication over RS485, along with a stack of 12 stored events for traceability.

The TELYS panel steps up with a larger display, voltmeter, frequency meter, ammeter, and USB and PC connectivity for remote operation and monitoring. For larger power plant applications, the APM802 offers a full touch-screen interface designed for hospitals, data centers, banks, and industrial operations, with modular expansion built in.

Enclosure and Fuel Tank Options

The D275 is available in a compact open version measuring 2900 mm long, 1300 mm wide, and 1670 mm tall with a 390-liter tank, or in soundproofed enclosures for quieter operation. The M227 soundproofed version reduces noise to 83 dB(A) at 1 meter and 73 dB(A) at 7 meters. For extended runtime, the M227 DW containment option increases tank capacity to 950 liters, while the M227 DW48 option extends capacity to 2130 liters for longer autonomy between refueling.

Why Choose the D275

Built to ISO 8528-1 standards and delivered with oil and cold-weather coolant rated to -30°C, the D275 combines Doosan's proven engine platform with flexible voltage configurations and scalable control options.

For facilities that need a compact, adaptable generator with straightforward operation, the D275 delivers dependable performance backed by a mechanically welded, vibration-isolated chassis built for long service life.
