40 kW 50 kVA Diesel Generator - John Deere

OVERVIEW

The John Deere 40KW, 50kVA 1 Phase Generator featuring a Tier 4 Interim compliant engine is designed for reliable power in stationary emergency applications. Featuring top-quality components and U.S.-based design and manufacturing, the John Deere 40KW Tier 4 Interim generator delivers best-in-class emergency backup power for industrial applications.

40KW John Deere Diesel Generator Standard Features and Capabilities:

Engine	John Deere heavy duty electronic diesel engine 4 stroke 1,800 RPM Turbocharged and aftercooled (air-to-air) U.S. EPA Tier 4i compliant engine for Stationary Emergency applications
Alternator	Designed and manufactured by Leroy Somer, a leading manufacturer of industrial alternators Features a Leroy Somer R220 Automatic Voltage Regulator Single bearing 3 phase 4 pole IP23 protection Insulation class H
Enclosure	Longer component lifespan and enhanced operator safety achieved through a 29dB(A) internal-mounted critical silencer and flexible exhaust connector Scratch- and corrosion-resistant automotive-grade textured finished with enhanced edge coverage Up to 51mm acoustic insulation with hydrocarbon sealing film meets FMVSS 302 flammability classification Easier access to the set controller, breaker and service points through multi-personnel doors Interchangeable panel construction allows for easy replacement and service access without compromising enclosure design Weather-protective design features a vertical air discharge outlet grille to redirect cooling air up and above the enclosure Meets and exceeds: NFX41002 Salt spray test NFT30049 UV Performance test NFT30038 Paint adhesion test 2000/14EC Low sound directives
Fuel Tank and Features	Incorporated metallic fuel tank for day use Electronic fuel level sender for easy monitoring
Control Panel and Features	Digital Deepsea DSE 7320 controller comes standard (Optional upgrade to Deepsea DSE 8610 for paralleling) Digital auto-start/stop control panel for enhanced control over generator operation CE and UL compliant for enhanced safety

Additional Features and Capabilities of the 40KW John Deere Diesel Generator Include:

Main line circuit breaker with a maximum output rated for complete protection
Auto-start control feature offers seamless interoperation with ATS/AMF
Quick and reliable startup with a 12V charged DC starting battery with electrolyte and cables
Enhanced operation and easier maintenance with standard installation of a dry type air filter, fuel filter and oil filter elements
Mechanically-welded chassis with vibration isolators deliver super-quiet operation
Accepts 100% rated load in one step as per NFPA110
Meets ISO8528-5 class G-3 for transient response
Compliant with:

ISO3046
ISO8528
BS4999
BS5514
BS5000PT99
AS1359
IEC34
UTE5100
VDE0530
ISO9001:2000

Compatible Accessories and Options for the 40KW John Deere Diesel Generator:

The 40KW John Deere diesel generator can be custom-configured to meet your unique power needs. Compatible accessories include:

Weatherproof and sound attenuated enclosures made with steel or aluminum
UL142 listed double wall fuel tanks from 50 to 10,000 gallons
UL1008 listed automatic transfer switches from 50 to 3,000 AMP
D.O.T. compliant heavy duty road trailers from 3000 to 30,000 pounds
Automatic battery chargers, engine preheaters, remote annunciators and many more easy-to-install accessories for enhanced generator performance
