GP-J350-60T3: 350 KW John Deere Diesel Generator

The GP-J350-60T3 is a fully packaged 350 kW, 438 kVA diesel generator built around a heavy duty John Deere engine and a Leroy Somer alternator, designed to deliver dependable emergency standby power for demanding commercial and industrial applications. Every unit is individually factory load bank tested before shipment, giving buyers confidence that the generator performs to specification from day one.

• JOHN DEERE 6135HFG84-1538 engine, US EPA Tier 3 compliant for stationary emergency use
• LEROY SOMER TAL-047-B alternator with IP23 protection and Insulation Class H
• DEEPSEA DSE7320 digital auto start/stop control panel with full CANBUS connectivity
• Standby power rating of 360/450 kWe/kVA and prime power rating of 324/405 kWe/kVA
• Main line circuit breaker rated for maximum output protection
• Incorporated metallic day tank with electronic fuel level sender
• 12V charging alternator, DC electric starter motor, and starting battery included
• Accepts 100 percent rated load in one step per NFPA110 and ISO8528-5 Class G-3
• Mechanically welded chassis with vibration isolators for reduced operating stress
• Compliant with ISO3046, ISO8528, BS4999, BS5514, IEC34, and ISO9001:2000
• Version: Enclosed (Fully Weather Proof Silent Enclosure)
• EPA Compliant: EPA Tier 3 Stationary Emergency

This generator set is engineered for facilities that cannot afford downtime, from hospitals and data centers to manufacturing plants and municipal infrastructure. With its combination of proven John Deere power and rigorous international compliance, the GP-J350-60T3 is built to perform when it matters most.

John Deere Engine Performance and Fuel Efficiency

At the heart of the GP-J350-60T3 is the John Deere 6135HFG84 engine, a turbocharged and aftercooled 6-cylinder unit with 13.5L displacement and electronic governing for precise speed control. Running at 1800 RPM, the engine produces a maximum standby output of 401 kW (538 HP) while maintaining efficient fuel consumption across load ranges, from 56.0 L/hr at 50 percent standby load to 99.2 L/hr at full standby load.

Depending on tank configuration, the unit can run continuously for anywhere from 7 hours on its integral 200-gallon tank at full load to 37 hours on an optional 1000-gallon external tank, giving operators flexibility to match runtime to their backup power needs.

Leroy Somer Alternator and Control System

The Leroy Somer TAL-047-B alternator is self-excited with an optional PMG configuration and features a 4-pole design with a 0.8 power factor. Voltage regulation is held within plus or minus 1.0 percent across the 0 to 100 percent range thanks to the Leroy Somer R250 automatic voltage regulator.

Controlling the entire system is the DeepSea DSE7320 panel, offering a 132x64 LCD display, a 250-event fault log, and remote monitoring options via Ethernet, RS485, or SMS through a GSM/SIM card. For facilities requiring multi-unit setups, the DSE8610 controller option supports paralleling of up to 32 generators with automatic load sharing and bus failure detection.

GP-J350-60T3 Enclosure and Build Quality

The generator is housed in the GP-6135 weatherproof, super silent enclosure, constructed from 12-gauge electro-zinc powder coated steel for corrosion resistance. An internal critical silencer keeps sound output to 29 dB(A), and up to 51mm of acoustic insulation meets FMVSS 302 flammability standards. Multi-personnel access doors, a tamper-proof viewing window, and an externally mounted emergency stop button round out the design for safe, convenient servicing.

Why Choose the GP-J350-60T3

Backed by General Power's manufacturing standards and available accessories including UL142 listed fuel tanks and UL1008 listed automatic transfer switches, the GP-J350-60T3 offers a complete, ready-to-install power solution. Whether for emergency backup or planned outage coverage, this unit delivers the reliability, compliance, and control features that critical operations demand.
