ACBCV600-60T2F - Volvo | 600 kW 750 kVA Diesel Generator

The ACBCV600-60T2F - Volvo | 600 kW 750 kVA generator delivers dependable three-phase power for facilities that cannot afford downtime. Built by Broadcrown around a Volvo TWD1643GE engine and a Stamford HCI 544 alternator, it is ready for demanding standby and prime applications.

• Standby power: 600 kW / 750 kVA
• Prime power: 555 kW / 694 kVA
• Frequency and phase: 60 Hz, 3-phase, 0.8 power factor
• Engine: Volvo TWD1643GE, 6-cylinder inline, 16.12 liters
• Alternator: CGT Stamford HCI 544, single bearing
• Engine speed: 1800 rpm
• Emissions: EPA Tier II Flex compliant
• Standard fuel tank: 161 gallons (609 liters)
• Controller: BC 7310 Digital Auto Start
• Voltage regulation: ± 1.0%
• Version: Enclosed (Fully Weather Proof Silent Enclosure)
• EPA Compliant: EPA Tier 2 Stationary Emergency

Voltage options range from 220/127 through 480/277, with 902 amps available at 480 volts on standby. All ratings follow ISO 8528-1 and ISO 3046-1 standards.

Volvo Engine Performance and Fuel Efficiency

The turbocharged, air-to-air charge cooled Volvo engine produces 904 bhp gross at standby output. An electronic governor with ECU and CANBus management keeps speed steady under changing loads.

• 100% standby load: 42.6 gal/h
• 75% standby load: 31.0 gal/h
• 50% standby load: 20.9 gal/h

These consumption figures help you plan runtime and refueling with confidence. The cooling system handles radiator air-on temperatures up to 129°F, and the engine is rated for altitudes up to 3,300 feet.

Inside the ACBCV600-60T2F - Volvo | 600 kW 750 kVA Alternator and Controls

The Stamford HCI 544 alternator is a 4-pole, self-excited design with Class H insulation and an AS 440 AVR. It pairs with the BC 7310 control system, based on the Deep Sea Electronics DSE7310, for manual and automatic remote starting.

• Coolant temperature and oil pressure monitoring with alarm and shutdown
• Under/over voltage and over current protection
• Digital display of frequency, kW, kVA, and power factor
• RS485 telemetry and automatic cool-down timer
• Emergency stop button

Operators get a clear view of engine and electrical conditions from a single LCD panel. Upgraded controllers are available for automatic mains failure operation and for set-to-set or set-to-mains synchronization.

Built for Demanding Job Sites

Every unit sits on a fully welded steel skid base with lifting points and heavy duty rubber anti-vibration mountings. The open set measures 146 inches long and 89 inches high, giving it a manageable footprint for a generator of this output.

• Radiator with pressure cap, drain point, and fully guarded engine-driven fan
• 24V starter batteries with a separate engine-driven charging alternator
• Spin-on oil and fuel filters with a dry type air filter element
• Industrial silencer with 15 dBA reduction, supplied loose
• Main line circuit breaker

Routine service is straightforward thanks to accessible filters and drain points. Each generator also ships with a factory test certificate and an operation and maintenance manual.

Options for the ACBCV600-60T2F - Volvo | 600 kW 750 kVA

Where noise or weather exposure is a concern, the optional Canopy 7 acoustic enclosure lowers typical sound levels to 78 dB(A) at 3 feet and 68 dB(A) at 23 feet. Its fully welded steel construction, rock wool lining, and lockable doors protect the set in harsh outdoor environments.

• Integral 377 gallon or bunded 344 gallon fuel tank with the enclosure
• Coolant heater and alternator anti-condensation heater
• Residential or critical grade silencers
• Low fuel level switches and fuel transfer systems
• Quadrature droop kit and thermistor probes

These options let you match the generator to your site, climate, and local noise requirements. Contact our team today for a quote and for help configuring the right package for your application.
