BCV 300-60 T3/F: 300 kW Volvo Generator

The BCV 300-60 T3/F is a 300 kW, 375 kVA diesel generator set built around a Volvo TAD 1351GE engine paired with a CGT Stamford alternator, engineered for facilities that demand EPA Tier III Flex compliant power. With full CANBus integration, a fully welded steel skid base, and a comprehensive digital control system, this generator delivers dependable performance backed by proven European engineering.

• Volvo TAD 1351GE engine, water cooled, 6-cylinder inline, ECU/CANBus equipped
• Single bearing CGT Stamford HCI 444 alternator, Class H insulation
• Standby power rating of 300 kWe / 375 kVA at 60Hz, 3-phase
• Prime power rating of 275 kWe / 344 kVA
• EPA Tier III Flex compliant emissions certification
• BC 7310 digital auto start control system with full CANBus implementation
• Main line circuit breaker included for complete protection
• Fully welded steel skid base with integral lifting points
• Integral fuel tank with filler cap and gauge, 188 gallon standard capacity
• Heavy duty rubber anti-vibration mountings and 24V starter batteries
• Version: Open Skid (Also Available Enclosed)
• EPA Compliant: EPA Tier 3 Stationary Emergency

This generator suits industrial sites, commercial facilities, and standby power applications across five voltage configurations, from 220/127V up to 480/277V. With factory testing, a full operation manual, and a wide range of optional features, the BCV 300-60 T3/F is built for straightforward installation and long-term reliability.

Volvo Engine Performance and Fuel Efficiency

The Volvo TAD 1351GE engine runs at a steady 1800 RPM with a turbocharged, air-to-air charge cooled design and a displacement of 12.78 liters. At standby rating, the engine delivers a net power output of 323 kWm (433 bhp), while prime rating produces 294 kWm (394 bhp).

Fuel consumption at 100 percent standby power comes in at 82.5 liters per hour (21.8 gal/hr), dropping to 62.4 liters per hour (16.5 gal/hr) at 75 percent load and 43.4 liters per hour (11.5 gal/hr) at 50 percent load. The standard fuel tank holds 711 liters (188 gallons), giving solid runtime between refuels.

Stamford Alternator and Electrical Output

The CGT Stamford HCI 444 alternator is a single bearing, directly coupled unit with a 4-pole, 3-phase winding design and Class H insulation. Self-excited with an AS440 automatic voltage regulator, it holds voltage regulation within plus or minus 1.0 percent.

The alternator is rated for a power factor of 0.8 and supports operating temperatures up to 40°C at prime rating. Across its five voltage configurations, the unit delivers consistent 300 kWe standby output whether wired for 480/277V, 440/254V, 416/240V, 240/138V, or 220/127V service.

Digital Control and Monitoring Options

The standard BC 7310 control system, based on the Deep Sea Electronics DSE7310 controller, provides manual and automatic remote start with full CANBus implementation for engine control and protection.

The LCD digital display covers coolant temperature, oil pressure, oil temperature, engine hours, battery voltage, volts, amps, frequency, kW, kVA, and power factor, all with appropriate alarm and shutdown protection. Facilities needing mains monitoring can step up to the BC 7320 for full AMF functionality, or choose the BC 8610 and BC 8620 systems for set-to-set or set-to-mains synchronization capability.

Enclosure and Sound Attenuation Options

The optional Canopy 5R acoustic enclosure provides a fully welded steel canopy finished in a two-pack polyurethane coating, designed to meet EU Legislation 2000/14/EC noise standards through extensive rock wool and perforated zintec steel lining. At standby power, the enclosed unit measures 78 dB(A) at 1 meter and 68 dB(A) at 7 meters.

The canopy integrates a steel fuel tank with a 260-gallon capacity, or a bunded configuration with a 236-gallon separate tank, along with side-opening doors, a control panel viewing window, and heavy duty locks for security.

Why Choose the BCV 300-60 T3/F

Engineered to ISO 8528-1 and ISO 3046-1 standards, the BCV 300-60 T3/F combines Volvo's proven engine platform with Stamford alternator technology and a flexible control system lineup. For facilities that need EPA Tier III Flex compliant standby power with strong documentation and a wide range of optional features, this generator delivers the reliability and adaptability that demanding installations require.
