ACBCMU1000S-60T2F - MTU | 1000 kW 1250 kVA Diesel Generator

The ACBCMU1000S-60T2F - MTU | 1000 kW 1250 kVA is a heavy duty diesel generator set built for facilities that cannot afford downtime. It pairs an MTU 16V 2000 G85 TD engine with a CGT Stamford HCI 634 alternator for dependable 60 Hz, 3-phase power.

• Standby rating: 1000 kWe / 1250 kVA
• Prime rating: 925 kWe / 1156 kVA
• Engine: MTU 16V 2000 G85 TD, 16 cylinder Vee, 4-stroke
• Alternator: CGT Stamford HCI 634 J, single bearing
• Frequency and speed: 60 Hz at 1800 rpm
• Voltages: 440/254, 220/127, and 254/127
• Power factor: 0.8
• Emissions: EPA Tier 2 Flex Certified
• Open set dimensions: 175 in L x 75 in W x 87 in H
• Operating weight: 16,373 lb
• Version: Enclosed (Fully Weather Proof Silent Enclosure)
• EPA Compliant: EPA Tier 2 Stationary Emergency

These ratings are stated at standard reference conditions in accordance with ISO 8528-1 and ISO 3046-1. Output may be subject to derate at different site temperatures and altitudes.

MTU Engine Performance and Fuel Efficiency

At the heart of this set is a turbocharged, air to air charge cooled engine with 31.84 litres of displacement. It delivers 1494 bhp gross at standby output. Governing is handled by the ADEC electronic governor with ECU and CANBus communication.

• Fuel use at 100% standby load: 70.7 gal/h
• Fuel use at 75% standby load: 53.6 gal/h
• Fuel use at 50% standby load: 36.6 gal/h
• Bore and stroke: 130 mm x 150 mm

Electronic engine management keeps speed stable as loads change. The result is predictable fuel consumption that makes tank sizing and runtime planning straightforward. A 24V electrical system with starter batteries and a separate engine driven charging alternator supports reliable starting.

ACBCMU1000S-60T2F - MTU | 1000 kW 1250 kVA Alternator and Electrical Output

The Stamford HCI 634 J alternator is manufactured by Cummins Generator Technologies. It is a 4-pole, 3-phase machine with Winding 311, directly coupled to the engine. Separate excitation by PMG supports strong performance under demanding loads.

• Standby output of 1640 amps at 440/254V
• Standby output of 3007 amps at 220/127V
• Standby output of 3280 amps at 254/127V
• Voltage regulation of ± 0.5% with the MX 321 AVR
• Class H insulation system

Tight voltage regulation protects sensitive equipment connected to the set. The standby rating is available for up to 500 hours per year at an average load of up to 85% of the rating. For prime duty, a 10% overload is available for 1 hour in every 12 hours of operation.

Control System and Monitoring Options

The standard BC 7310 Digital Auto Start control system is based on the Deep Sea Electronics DSE7310 controller. It provides manual and automatic remote start along with full CANBus engine control and protection. An LCD display puts key engine and electrical data in front of the operator.

• Coolant temperature and oil pressure alarms with shutdown
• Under and over voltage protection plus over current protection
• Frequency, kW, kVA, and power factor readouts
• RS485 telemetry, cool-down timer, and emergency stop button

Upgrades are available for more complex installations. The BC 7320 adds full AMF functionality with integrated mains monitoring. The BC 8610 and BC 8620 add set-to-set and single set-to-mains synchronisation.

Why Choose the ACBCMU1000S-60T2F - MTU | 1000 kW 1250 kVA

This generator arrives as a complete open set package ready for installation. Its construction focuses on durability and simple servicing. Every unit ships with a Factory Test Certificate and an Operation and Maintenance Manual.

• Fully welded steel baseframe with lifting and jacking points
• Heavy duty rubber anti-vibration mountings
• Radiator with pressure cap, drain point, and fully guarded fan
• Spin on oil and fuel filters with a dry type air filter element

Various fuel system options and a wide range of optional extras allow the set to be tailored to your site. Contact our team today to request a quote on this 1000 kW MTU generator.
