CUMMINS 80 KW Generator 80 KVA, Single Phase, Brand New
BCC80 Broadcrown Generator, Open type, EPA compliant

The Broadcrown BCC 80-60SP T3/F is a robust power generation solution built for reliable performance. This unit features an efficient water-cooled diesel engine paired with a single-bearing alternator.

Key Specifications:

• Generator Model: Broadcrown BCC 80-60SP T3/F
• Alternator: Single-bearing CGT Stamford UCI 274 / UCDI 274 C with Class H insulation system and SX 460 AVR
• Prime Power Output: 80 kWe / 80 kVA
• Standby Power Output: 80 kWe / 80 kVA
• Frequency and Phase: 60 Hz, 1-Phase
• Voltage Options: 240/120V (333 Amps) or 220/110V (364 Amps)
• EPA Compliance: EPA Tier 3 Stationary Emergency
• Version: Open Skid (Also Available Enclosed)

The design incorporates heavy-duty rubber anti-vibration mountings to ensure smooth operation. Furthermore, the system includes a standard factory test certificate and an operation and maintenance manual.

Engine Specifications of the BCC 80-60SP T3/F

Under the hood, this model relies on a powerful Cummins QSB5-G4 engine running at 1800 rpm. This four-cylinder, inline, four-stroke engine is turbocharged and features air-to-air charge cooling. Additionally, it couples with a CGT Stamford UCDI 274 C alternator equipped with a class H insulation system.

Advanced Control Systems

Operations are managed seamlessly by the BC 7210 Auto Start system, which utilizes the DSE 7210 control module.

This module offers features like automatic remote start, overspeed protection, and low oil pressure protection. It also includes underspeed protection and high coolant temperature protection. Digital displays keep operators informed about volts, amps, frequency, and engine operating hours.

Optional Acoustic Enclosure for the Broadcrown BCC 80-60SP T3/F

For tough environments, buyers can select the optional Canopy 2 acoustic enclosure. It is designed with fire-retardant polyurethane foam to manage noise efficiently and includes heavy-duty locks on all doors for maximum security.

A steel fuel tank is integrated within the baseframe to provide convenience.
