The Powerful SDMO J110K Generator

The SDMO J110K is a power solution designed to meet your energy needs reliably. This generator provides performance for standby and prime power applications.

Key Specifications:

• Engine: JOHN DEERE 4045HF120
• Standby Power Output: 88 kWe (110 kVA) for emergency power supply
• Alternator: AT00911T with IP 23 protection
• Voltage & Frequency: Standard 400/230 V at 50 Hz
• Fuel Tank Capacity: 190 Liters
• EPA Compliance: Export Only
• Version: Enclosed (Fully Weather Proof Silent Enclosure)

These specifications ensure your operations remain running smoothly during unexpected emergencies. The unit comes delivered with oil and coolant for a straightforward setup.

Control Panels for the J110K

The standard control panel is the versatile APM303. Equipped with an LCD screen, it offers high-quality basic functions to guarantee simple operation. It provides measurements like phase-to-neutral voltages and coolant temperature levels.

The optional TELYS control unit is also available. It places the accent on simplicity with its large display screen, buttons, and scroll wheel.

Engine and Alternator Details

The engine features a four-cylinder L arrangement with a 4.48 displacement. It operates at a speed of 1500 RPM and utilizes a mechanical governor. The cooling system uses a glycol-ethylene coolant and has a maximum water temperature of 105°C.

Fuel consumption is efficient, using 23.50 L/h at 100% load and 11.50 L/h at 50% load. The alternator features an IP 23 protection indication and uses technology without a collar brush.

Dimensions of the SDMO J110K

The compact version has a length of 1950 mm, a width of 1084 mm, and a height of 1330 mm, with a dry weight of 1187 kg. The soundproofed version, commercial reference M129, measures 2554 mm in length and 1680 mm in height, weighing 1587 kg dry.
