Broadcrown BCY 18-60 Generator

The Broadcrown BCY 18-60 is a robust and reliable power generation solution designed to meet demanding operational needs. This generator combines top-tier components to deliver consistent 3-phase power at 60 Hz.

Key Specifications:

• Engine: Efficient, water-cooled Yanmar 4TNV 88 diesel engine.
• Power Output: 18 kWe / 23 kVA for both Prime and Standby Power configurations.
• Electrical: 3-Phase, 60 Hz operation with multiple voltage options including 480/277V and 240/138V.
• Alternator: Single-bearing CGT Stamford PI 144 alternator.
• Control System: BC 7210E-M Auto-Start control system for reliable automated operation.
• Dimensions & Weight (Open Set): 1325 mm (L) x 610 mm (W) x 1314 mm (H) with a standard operating weight of 703 kg.
• EPA Compliance: Export Only
• Version: Enclosed (Fully Weather Proof Silent Enclosure)

With its heavy-duty rubber anti-vibration mountings, this unit ensures stable operation across various industrial environments. Every generator includes a factory test certificate alongside a comprehensive operation and maintenance manual to guarantee quality right out of the box.

Advanced Control Systems of the BCY 18-60

The standard BC 7210E-M Auto Start system provides automatic remote start capabilities and clear digital displays for volts, amps, and frequency. It also ensures your equipment remains safe from damage with comprehensive built-in protections against overspeed, underspeed, low oil pressure, and high coolant temperatures.

Optional Acoustic Enclosure for the BCY 18-60

For operators working in harsh outdoor environments, the optional Midi 1 Canopy offers an exceptional blend of security and acoustic performance. This protective enclosure features a side opening door for straightforward maintenance access, a panel viewing window in the main door, and heavy-duty locks to ensure total security.

Additional Customization and Options

You can further customize your generator equipment with a wide range of optional extra features. Popular open set modifications include an electronic governor, extended oil and coolant drains, or an anti-condensation heater for the alternator, ensuring the unit perfectly matches your specific site requirements.
