OVERVIEW
DESCRIPTION:
- The AVR model R630 is composed of electronic cards which are included in a rack 19" .
- Except the necessary "Generator I/O", the optional "mains I/O" located on the left of the rack and the "driver" card located on the right, all the other cards can be plugged anywhere in the rack. Future optional cards could be added without any internal wiring modification.
- The rear flat cable (BUS 64 points) is given more long as it can be connected to an optional interface terminal block which gives all the internal test points or in the future the possibility to connect another rack if the cards number will become too important.
