SDMO J165K Generator: Built for Demanding Environments

The SDMO J165K is a highly dependable and robust power generation solution built to tackle your demanding industrial energy needs. Powered by a heavy-duty engine, this premium generating set ensures consistent performance for various complex applications.

Key Specifications:

• Engine: John Deere 6068HF120-153 diesel engine
• Standby Power Output: 132 kWe and 165 kVA at 400/230V for emergency backup
• Alternator: AT01340T model featuring direct coupling and mechanic governor
• Control Panel: APM303 interface
• Fuel Tank: 340-liter capacity
• EPA Compliance: Export Only
• Version: Open Skid (Also Available Enclosed)

This premium unit features a mechanically welded chassis equipped with an antivibration suspension to minimize operational wear. Furthermore, it includes an industrial radiator designed for maximum wiring temperatures of 48/50 degrees Celsius.

Power and Efficiency of the SDMO J165K

This exceptional generator operates at a standard frequency of 50 Hz and falls under the G3 performance class. When running at full capacity, the fuel consumption at 100% load is rated at an efficient 33.50 liters per hour. The internal engine operates smoothly at 1500 RPM with a 6.72-liter displacement.

SDMO J165K Dimensions and Enclosures

The compact open version of this generator has a dry weight of 1578 kg. It measures 2370 mm in length, 1114 mm in width, and 1480 mm in height. For demanding environments requiring noise reduction, soundproofed enclosures like the M226 are readily available.

This soundproofed variation guarantees a sound power level of 94 LWA and includes a protective grille.

Advanced Control System Options

Operators can comfortably manage the generating set using the versatile APM303, which provides a user-friendly LCD screen and essential safety features like overspeed monitoring. For enhanced capabilities, users can upgrade to the ergonomic TELYS panel.

This advanced system offers a prominently large display, an intuitive scroll wheel, and direct PC connections.
