SDMO T33K Generator

The SDMO T33K is a highly efficient generating set built to deliver dependable power across various applications. This robust unit features a mechanically welded chassis equipped with an antivibration suspension to ensure smooth operation.

Key Specifications:

• Product Series: SDMO model T33K generator
• Engine: Mitsubishi S4S-SD four-cylinder engine with an L-arrangement
• Frequency and Speed: Standard frequency of 50 Hz and an engine speed of 1500 RPM
• Alternator: Direct-coupled AT00630T three-phase alternator with 0.80 power factor and class H continuous insulation
• EPA Compliance: Export Only
• Version: Enclosed (Fully Weather Proof Silent Enclosure)

The system comes with a standard APM303 control panel for reliable operation and supervision. It also includes a radiator designed for a maximum wiring temperature of 48/50°C.

Engine Details for the T33K

Powering this model is a reliable four-cylinder Mitsubishi S4S-SD engine. The displacement is 3.33 C.I., and it utilizes a mechanical governor type to maintain steady performance.

 It operates at a speed of 1500 RPM while maintaining an oil capacity of 10 L and a minimum oil pressure of 1 bar. Fuel consumption is 8.20 L/h at 100% load.

Advanced Control Panels

The standard APM303 control unit operates in manual or automatic mode and displays phase-to-neutral and phase-to-phase voltages alongside active power currents. Users can also upgrade to the optional TELYS panel.

The TELYS system provides a large display screen and ergonomic scroll wheel, monitoring engine parameters like working hours, coolant temperature, and fuel level.

Dimensions of the T33K

The compact version of this model has a length of 1700 mm, a width of 896 mm, and a height of 1144 mm. Its dry weight is 670 kg.

The soundproofed version extends the length to 2080 mm and weighs 900 kg. Both configurations guarantee exceptional utility for your power generation needs.
