Broadcrown BCY 13-60SP T4 Generator

The Broadcrown BCY 13-60SP T4 is a reliable power solution designed for demanding applications. This robust unit combines a high-quality engine with a dependable alternator to deliver consistent electrical output.

Key Specifications:

• Engine: Efficient, water-cooled Yanmar 3TNV 88 diesel engine.
• Power Output: Reliable 13 kW (13 kVA) output for both Prime and Standby applications.
• Alternator: Premium single-bearing CGT Stamford PI 044 alternator.
• Electrical Configuration: 60 Hz, 1-Phase operation offering 240/120 or 220/110 voltages.
• Emissions Compliance: Fully EPA Tier 4 Certified for clean, standard-compliant operation.
• Control System: Integrated BC 7210E-M Auto-Start control system for seamless management.
• EPA Compliance: Export Only
• Version: Enclosed (Fully Weather Proof Silent Enclosure)

Built on a fabricated steel skid base with forklift pockets, this generator ensures easy transportation and installation. It also features a molded polypropylene fuel tank and heavy-duty rubber anti-vibration mountings to guarantee long-lasting durability.

Engine and Alternator Details for the BCY 13-60SP T4

The heart of this generator is its 3-cylinder, inline, 4-stroke Yanmar engine. Operating at 1800 rpm, it provides a gross power of 15.4 kWm for both standby and prime applications. The direct-coupled Stamford alternator utilizes a Class H insulation system and features a self-excited excitation system. Furthermore, voltage regulation is tightly maintained at $\pm1.0\%$ through an SX 460 AVR.

Advanced Control System of the BCY 13-60SP T4

The standard BC 7210E-M system, based on the DSE 7210 module, offers comprehensive oversight. It provides automatic remote start capabilities alongside vital overspeed, underspeed, low oil pressure, and high coolant temperature protections. Digital displays clearly show volts, amps, frequency, and engine operating hours.

Optional Acoustic Enclosure

For environments requiring reduced noise levels, the Midi Canopy M1 is available as an optional acoustic enclosure. It is designed to meet EU Legislation 2000/14/EC requirements using fire-retardant polyurethane foam. The canopy includes internally mounted high-performance exhaust silencers and heavy-duty locks on all doors for maximum security.
