DSE9461-01 LCD - Deep Sea

Worldwide Warranty
Quick Shipping
24/7 Support
SKU:
9461-01
Availability:
IN STOCK, Same day shipping Worldwide available
In Store Pick Up:
Available Mon-Fri 9AM-5PM
Condition:
Brand New, 1 Year International Warranty
Quality:
Individually factory tested and certified
Reliability:
100% Made in UK (0% China)

OVERVIEW



Deep Sea DSE9461 Battery Charger

Leading manufacturer Deep Sea Electronics provides its top of the line products to over 150 countries. This UK company has been providing intelligent battery chargers and generator controllers available in 12, 24 and 48 volts for over 40 years now and shows no signs of slowing down.

DEEPSEA 9461-01 Generator Battery Charger

The DSE9461-01 battery charger is a 12 volt, 10 amp model designed with an LCD display. This charger has been optimized for high levels of battery longevity, performance, utility and safety. In addition to default charging curve configuration, the user can also directly modify the application to operate under their own desired parameters for alternative battery types. The inputs and outputs are thoroughly protected to facilitate risk-free charging.



SPECIFICATIONS:

  • Voltage Range (L-N): 90V to 305V
  • DC Output: 10 Amp 12 Volt
  • Frequency Range: 48 Hz to 64 Hz
  • Ripple/Noise: <1%
  • Efficiency: >86%
  • Regulation:
    • Line: <0.5% Vo
    • Load: 2% Vo
  • Auxiliary Input: 100 mA DC at 12 volts
  • Protections:
    • Short Circuit
    • DC Over Voltage
    • DC Over Current
    • Reverse Polarity
    • Over Temperature
    • AC Under & Over Voltage
    • Battery Charger Failure
  • Operating Temperature Range: -30 °C to +55 °C
  • Storage Temperature Range: -40 °C to +85 °C



PRINCIPAL FEATURES AND BENEFITS:

  • An external LCD can be used to remotely examine the charging status
  • With an RS485 cable, MODBUS RTU can be used to integrate the charger into external systems/li>
  • The battery's condition can be maintained with either Manual or Automatic boost storage charge functionality
  • DSE Configuration Suite PC Software can be used to flexibly configure the charger's settings
  • Compatible with a wide range of different types of batteries
  • Battery's lifespan is always optimized for maximum length
  • LCD Display



DIMENSIONS:

  • 6.49" x 12" x 4.33"
  • WEIGHT: 5.06lb
